1. Wire To Be Processed :

(1)

Single band wire with diameter of 0.3~5.0m/m.

(2)

Various single core wires.

(3)

Separated wires.

(4)

Aligned Wires.

(5)

Parallel Wires.

(6)

Computer Wires.

2. Production Capacity :

        Depends on diameter of the electric wire. Take wires under UL26 AWG for instance. 10 pieces of wire can be cut in one time. For wires less than 510m/m long. 21,000 pieces of wire can be produced per hour. For wire length of 510m/m-1,000m/m. 10,500 pieces can be produced per hour. For processed 22 or 24 AWG wires, 8 pieces of wire can be cut in one time. for wires above 20 AWG, 5 pieces of wire can be cut in one time.

3. Processed Range :

(1)

Max. cutting length : 5,000 m/m~9,300 m/m.

(2)

Min. cutting length : 25 m/m~60 m/m

(3)

Max. cutting length for one stroke : 510 m/m~810 m/m.

(4)

Max. stripping length : 75 m/m.

(5)

Min. stripping length : 2.5 m/m.
